Daily inspection of equipment in the production line of non fired brick machine

In order to ensure the normal operation of the equipment of the non fired brick machine production line, the following conditions must be met:

Press the pressure control button to confirm that the reading of the output gauge installed on the pump body is “0″, and the current of the oil pump drive motor is not higher than the maximum power limit. If the conditions cannot be met, contact the technical service department of hydraulic brick making machine company. Check the grounding electrode of the hydraulic brick making machine and the grounding between the beam and the punch. Reconnect if necessary. Grounding terminal: A, beam B, punch C, equipment base. In addition, check the grounding connection of the die. Before tightening the provided wiring screws, remove the paint on the grounding point of the machine body to ensure good electrical contact. If the grounding is poor, the operator may be seriously injured and the equipment may be damaged. Clean the mold air filter: remove the filter, clean it with compressed air, check the filter and seal, and pay special attention to the correct position of the seal when tightening the cover. Replace the filter if necessary. Check the efficiency of safety devices: functions of all safety devices, emergency stop buttons, micro switches and protective switching devices, etc.

Replace the air filter element of the pre pressurization system: replace the filter element at least once a year. Check the effectiveness of the dust collection system: confi that the dust collection is well connected and that the system operation meets the technical requirements of sakmi. Replace the hydraulic pump oil: when changing the oil, pay attention to remove any possible sediment inside the oil storage tank, and use the hydraulic oil that meets the requirements. Check the efficiency of oil / water radiator: confirm that the oil temperature is within the allowable range and there is no sudden increase. Replace the rising oil pipe of punch: drain the oil in the hydraulic brick press and replace the pipeline. Replace the booster rising oil pipe: drain the oil in the equipment, remove the booster cover and replace the oil pipe.
