Advantages of Hercules block machine

Advantages of Hercules block machine

   1). Components of the block machine like face mix feeding box and base mix feeding box all can be detached from the main machine for maintenance and cleaning.

2). All the parts are designed to be easily changeable. Bolts and nuts design are used widely instead of welding. All the parts are tool and worker accessible. Each part of main machine can be set detachable. In that way, if one part goes wrong, you just need to change the broken one instead of the whole part.

3). Unlike other supplies, there are only two wearable plates under the feeder box instead of multiple wearable plates, which decreases the negative effect of uneven distribution of material because of too many gaps between the plates.

4). The height of the material feeder is adjustable, therefore we can control the gap between the feeder and the filling box table/bottom mould (1-2mm is the best), so as to prevent the leakage of the material. (Traditional Chinese Machine cannot adjust)

5). The machine is equipped with synchronized beam which we call mould leveling device to keep the mould in balance, so as to get higher quality blocks. (Traditional Chinese Machine does not have the synchronized beams)

6). Electric vibrator is applied. It is easy to repair with lower cost and shorter cycle time. For circle time, paver with face mix is less than 25s, while without face mix is less than 20s.

7). The air bags is used to protect the machine from destructive damage.

8). There are encoder with material feeder, we can adjust the speed and range according to different requirements. (Traditional Chinese machine only have one fixed speed)

9). The feeder is equipped with two hydraulic driven. It is more stable with lower noisy using buffer, so extending longer lifetime as a result. (Tradition Chinese Machine only equips with one hydraulic arm which could be possibly shaking during the feeding)

10). The feeding box is equipped with adjustable divider designed according to different type of block to guarantee the even distribution and efficiency of feeding process. (Traditional machine’s space in feeding box is fixed, could not be adjustable)

11). The hopper is equipped with two leveling sensor inside the hopper and it can tell the machine when to mix and transport the material to the machine. (Traditional Machine is controlled by time setting)

12). The cuber is driven by motor with adjustable speed and rotating angle and can cube all kinds of block. (Traditional machine is with only one single speed and can only rotate 90 degree left and right; There would be problem when the traditional machine is cubing the small size of brick/paver/block)

13). The finger car is completed with brake system, being more stable and highly precise positioning.

14). The machine can make any kind of blocks and bricks, height ranged from 50-400mm 400mm.

15). Easy to change the mould with optional mould changing device, usually in half to one hour.
